1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084608.A3
084608
|
£251.17
|
£301.40
|
|
|
1.1 - INDUCTOR WITH COIL 230 V
MAF-084577.A4
084577
|
£214.50
|
£257.40
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-203849.A4
203849
|
£97.77
|
£117.32
|
|
|
2 - ARMATURE, BALANCED
MAF-088205.A2
088205
|
£281.07
|
£337.28
|
|
|
3 - GEAR CASING
MAF-200952.A12
200952
|
£500.01
|
£600.01
|
|
|
4 - HANDLE
MAF-203387.A2
203387
|
£54.30
|
£65.16
|
|
|
5 - CONTROL MODULE
MAF-077127.A5
077127
|
-
|
|
|
|
12 - STOP PLATE
MAF-200954.A12
200954
|
£121.88
|
£146.25
|
|
|
13 - BEARING COVER
MAF-200956.A1
200956
|
£60.38
|
£72.46
|
|
|
21 - HANDLE SHELLS (PAIR)
MAF-200960.A10
200960
|
£35.96
|
£43.15
|
|
|
22 - MOTOR COVER
MAF-204643.A5
204643
|
£36.83
|
£44.20
|
|
|
23 - SWITCH LEVER
MAF-201114.A9
201114
|
£13.23
|
£15.88
|
|
|
24 - COVER
MAF-200962.A0
200962
|
£5.31
|
£6.37
|
|
|
25 - LOCKING LEVER
MAF-201745.A2
201745
|
£6.02
|
£7.22
|
|
|
27 - CHAIN GUARD
MAF-200961.A15
200961
|
£22.32
|
£26.79
|
|
|
28 - AIR CONDUCTING RING
MAF-204743.A5
204743
|
-
|
|
|
|
30 - FAN, UPPER
MAF-032355.A5
032355
|
£12.50
|
£15.00
|
|
|
34 - GEAR SHAFT
MAF-200959.A9
200959
|
£214.56
|
£257.47
|
|
|
35 - LOCKING BOLT
MAF-200963.A7
200963
|
£36.52
|
£43.82
|
|
|
37 - DEPTH STOP
MAF-200964.A6
200964
|
-
|
|
|
|
39 - GUIDE PIECE
MAF-200965.A1
200965
|
£65.50
|
£78.60
|
|
|
43 - CONNECTING CABLE
MAF-085176.A3
085176
|
£6.70
|
£8.04
|
|
|
44 - RETAINING SPRING
MAF-200977.A5
200977
|
£13.08
|
£15.70
|
|
|
45 - CABLE CLAMP
MAF-029584.A40
029584
|
-
|
|
|
|
47 - PAD
MAF-201872.A29
201872
|
-
|
|
|
|
48 - BRUSH HOLDER
MAF-063148.A10
063148
|
£10.30
|
£12.36
|
|
|
49 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063176.A0
063176
|
£16.56
|
£19.87
|
|
|
50 - SKALE
MAF-077087.A10
077087
|
£9.51
|
£11.41
|
|
|
51 - CABLE PROTECTING SLEEVE
MAF-086065.A11
086065
|
£3.46
|
£4.15
|
|
|
52 - MAINS CABLE 10 M (32.8 FT.)
MAF-087612.A5
087612
|
£72.48
|
£86.98
|
|
|
54 - 2-POLE SWITCH
MAF-087878.A6
087878
|
£43.75
|
£52.50
|
|
|
54.2 - CHEESE-HEAD SCREW
MAF-005521.A5
005521
|
-
|
|
|
|
54.3 - PRESSURE SPRING
MAF-066078.A9
066078
|
-
|
|
|
|
54.4 - RETAINING CLIP
MAF-201155.A3
201155
|
-
|
|
|
|
56 - THREADED PIN
MAF-005284.A2
005284
|
-
|
|
|
|
57 - FLAT-HEAD SCREW
MAF-005371.A13
005371
|
£2.31
|
£2.77
|
|
|
58 - FLAT-HEAD SCREW
MAF-005372.A13
005372
|
£1.98
|
£2.38
|
|
|
60 - CYLINDER-HEAD SCREW
MAF-055214.A1
055214
|
£1.82
|
£2.18
|
|
|
61 - CYLINDER-HEAD SCREW
MAF-055074.A10
055074
|
£2.11
|
£2.53
|
|
|
62 - CYLINDER-HEAD SCREW
MAF-055041.A7
055041
|
£1.65
|
£1.98
|
|
|
64 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055079.A21
055079
|
£1.32
|
£1.58
|
|
|
65 - OVAL-HEAD SCREW
MAF-055258.A6
055258
|
£1.65
|
£1.98
|
|
|
66 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055187.A8
055187
|
£1.92
|
£2.30
|
|
|
68 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A38
055061
|
£1.71
|
£2.05
|
|
|
69 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A34
053020
|
-
|
|
|
|
72 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055062.A0
055062
|
-
|
|
|
|
75 - HEXAGONAL NUT
MAF-005924.A4
005924
|
£1.67
|
£2.00
|
|
|
77 - SQUARE NUT
MAF-005972.A11
005972
|
£1.93
|
£2.32
|
|
|
79 - CYLINDRICAL PIN
MAF-058153.A17
058153
|
£3.56
|
£4.27
|
|
|
80 - WASHER
MAF-061128.A14
061128
|
£1.50
|
£1.80
|
|
|
81 - SHIM RING
MAF-006160.A7
006160
|
£1.65
|
£1.98
|
|
|
83 - WASHER
MAF-061013.A9
061013
|
-
|
|
|
|
84 - LOCKING WASHER
MAF-061073.A8
061073
|
-
|
|
|
|
85 - RETAINING RING
MAF-061163.A14
061163
|
-
|
|
|
|
87 - WASHER
MAF-061047.A3
061047
|
£1.72
|
£2.07
|
|
|
89 - GROOVED BALL BEARING
MAF-062018.A15
062018
|
£26.06
|
£31.27
|
|
|
90 - GROOVED BALL BEARING
MAF-006260.A3
006260
|
£18.15
|
£21.78
|
|
|
91 - GROOVED BALL BEARING
MAF-062073.A32
062073
|
£14.28
|
£17.14
|
|
|
92 - GROOVED BALL BEARING
MAF-006288.A11
006288
|
£8.82
|
£10.58
|
|
|
94 - CONNECTING CABLE YELLOW
MAF-085183.A1
085183
|
£6.51
|
£7.81
|
|
|
99 - STICKER
MAF-070644.A0
070644
|
-
|
|
|
|
100 - SEALING RING
MAF-065015.A0
065015
|
£3.01
|
£3.61
|
|
|
101 - KNURLED KNOB
MAF-065034.A2
065034
|
£14.97
|
£17.96
|
|
|
102 - FELT RING
MAF-065035.A8
065035
|
-
|
|
|
|
103 - SEALING RING
MAF-006591.A8
006591
|
£1.65
|
£1.98
|
|
|
104 - PRESSURE SPRING
MAF-066043.A4
066043
|
£3.04
|
£3.65
|
|
|
108 - CLAMPING LEVER
MAF-007193.A5
007193
|
£13.11
|
£15.73
|
|
|
109 - CLAMPING LEVER
MAF-007192.A8
007192
|
£15.14
|
£18.17
|
|
|
500 - CHAIN BAR, CPL.
MAF-091015.A0
091015
|
£610.49
|
£732.59
|
|
|
500.2 - ROLLER
MAF-203535.A3
203535
|
£33.49
|
£40.19
|
|
|
500.3 - CHAIN TENSIONING PIECE
MAF-200974.A11
200974
|
£29.16
|
£34.99
|
|
|
500.4 - PRESSURE BIT
MAF-200976.A8
200976
|
£3.28
|
£3.94
|
|
|
500.5 - SHIM RING
MAF-006131.A12
006131
|
£2.48
|
£2.97
|
|
|
500.6 - SPACER DISK
MAF-203539.A3
203539
|
£10.72
|
£12.87
|
|
|
500.7 - THREADED PIN
MAF-005276.A4
005276
|
£1.81
|
£2.17
|
|
|
500.8 - CYLINDRICAL PIN
MAF-058202.A7
058202
|
£4.02
|
£4.82
|
|
|
500.9 - FLAT-HEAD SCREW
MAF-005383.A2
005383
|
£2.68
|
£3.22
|
|
|
500.10 - GROOVED BALL BEARING
MAF-062092.A1
062092
|
£5.73
|
£6.88
|
|
|
503 - MORTISING CHAIN
MAF-091237.A1
091237
|
£780.08
|
£936.09
|
|
|
503.1 - REPLACEMENT CHAIN LINKS + RIVETS
MAF-091281.A2
091281
|
-
|
|
|
|
504 - SPROCKET
MAF-091685.A3
091685
|
£98.08
|
£117.69
|
|
|
507 - ALLEN KEY
MAF-093070.A13
093070
|
-
|
|
|
|
508 - ALLEN KEY
MAF-093074.A17
093074
|
£2.95
|
£3.54
|
|
