2 - ARMATURE
MAF-088228.A1
088228
|
£176.00
|
£211.20
|
|
|
3 - GUIDE TRACK AS OPTIONAL ACCESSORY
MAF-204010.A4
204010
|
-
|
|
|
|
3.1 - GUIDE TRACK
MAF-205500.A2
205500
|
-
|
|
|
|
3.2 - RATCHET
MAF-203989.A6
203989
|
-
|
|
|
|
3.3 - STOP BOLT
MAF-204014.A1
204014
|
£13.08
|
£15.69
|
|
|
3.4 - STOP PLATE
MAF-203988.A14
203988
|
£4.72
|
£5.67
|
|
|
3.5 - INDICATOR
MAF-203987.A13
203987
|
£9.24
|
£11.09
|
|
|
3.6 - EDGE PROTECTION
MAF-203986.A2
203986
|
£4.94
|
£5.93
|
|
|
3.7 - STOP PLATE
MAF-204005.A2
204005
|
-
|
|
|
|
3.8 - COVER
MAF-203990.A6
203990
|
-
|
|
|
|
3.9 - SPRING GUIDE
MAF-203992.A10
203992
|
-
|
|
|
|
3.11 - HANDLE
MAF-204007.A8
204007
|
-
|
|
|
|
3.12 - STOP BUFFER
MAF-204009.A16
204009
|
-
|
|
|
|
3.13 - POLYETHYLENE CABLE
MAF-205586.A2
205586
|
-
|
|
|
|
3.14 - LEG SPRING
MAF-066155.A9
066155
|
-
|
|
|
|
3.15 - SKALE
MAF-203993.A7
203993
|
-
|
|
|
|
3.16 - SPLINTER GUARD F-SS 3,4M
MAF-204375.A2
204375
|
£21.99
|
£26.39
|
|
|
3.17 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055187.A32
055187
|
£1.92
|
£2.30
|
|
|
3.20 - CYLINDER-HEAD SCREW
MAF-055059.A6
055059
|
-
|
|
|
|
3.22 - WASHER
MAF-006102.A58
006102
|
-
|
|
|
|
3.23 - HEXAGON-HEAD SCREW
MAF-005688.A12
005688
|
-
|
|
|
|
3.24 - HEXAGONAL NUT
MAF-005915.A16
005915
|
-
|
|
|
|
3.25 - NON-SLIP PROFILE F-HP 6,8 M
MAF-204376.A4
204376
|
£21.08
|
£25.29
|
|
|
3.26 - HEXAGONAL NUT
MAF-005939.A38
005939
|
-
|
|
|
|
3.27 - SLEEVE
MAF-204237.A5
204237
|
-
|
|
|
|
3.28 - GROOVED BALL BEARING
MAF-062090.A2
062090
|
-
|
|
|
|
3.30 - STOP PLATE
MAF-205442.A5
205442
|
£24.26
|
£29.11
|
|
|
4 - GEAR CASING
MAF-201438.A4
201438
|
£138.16
|
£165.79
|
|
|
5 - BASE PLATE
MAF-203995.A3
203995
|
£126.12
|
£151.35
|
|
|
5.1 - SPRING DOWEL SLEEVE
MAF-005816.A9
005816
|
-
|
|
|
|
6 - TILTING SUPPORT
MAF-203994.A5
203994
|
-
|
|
|
|
7 - PROTECTIVE COVER
MAF-204011.A4
204011
|
£97.02
|
£116.42
|
|
|
8 - GEAR CASING COVER
MAF-200035.A4
200035
|
-
|
|
|
|
9 - SEGMENT
MAF-203996.A2
203996
|
-
|
|
|
|
12 - MOTOR CASING
MAF-205761.A0
205761
|
-
|
|
|
|
13 - HANDLE SHELL
MAF-205765.A2
205765
|
-
|
|
|
|
14 - MOTOR COVER
MAF-205763.A3
205763
|
-
|
|
|
|
15 - AIR CONDUCTING RING
MAF-205766.A0
205766
|
-
|
|
|
|
16 - SWITCH TRIGGER
MAF-205390.A3
205390
|
-
|
|
|
|
17 - LOCKING LEVER
MAF-205370.A1
205370
|
-
|
|
|
|
18 - HANDLE INSERT
MAF-203877.A19
203877
|
£19.14
|
£22.97
|
|
|
19 - LOCK-OFF BUTTON
MAF-205389.A2
205389
|
-
|
|
|
|
21 - PUSH-BUTTON
MAF-205767.A1
205767
|
-
|
|
|
|
22 - TRACING POINTER
MAF-204002.A1
204002
|
-
|
|
|
|
23 - SEGMENT FOR TILTING
MAF-203997.A2
203997
|
-
|
|
|
|
24 - PROTECTIVE COVER
MAF-205768.A1
205768
|
£19.36
|
£23.23
|
|
|
25 - COVER
MAF-200078.A8
200078
|
-
|
|
|
|
26 - SLEEVE
MAF-200048.A6
200048
|
-
|
|
|
|
27 - CAP
MAF-202345.A6
202345
|
£5.74
|
£6.89
|
|
|
29 - PAD
MAF-201872.A39
201872
|
-
|
|
|
|
31 - SHEET METAL DEFLECTOR
MAF-204012.A1
204012
|
-
|
|
|
|
32 - LEVER JOINT
MAF-201442.A1
201442
|
£13.08
|
£15.69
|
|
|
33 - CLAMPING CLAWS
MAF-200050.A13
200050
|
£4.32
|
£5.18
|
|
|
34 - RIVING KNIFE/SPLITTER SUPPORT
MAF-201441.A6
201441
|
-
|
|
|
|
35 - RIVING KNIFE/SPLITTER
MAF-202580.A5
202580
|
£10.26
|
£12.31
|
|
|
37 - CLAMPING LEVER
MAF-201433.A7
201433
|
-
|
|
|
|
38 - LOCKING LEVER
MAF-205764.A0
205764
|
-
|
|
|
|
40 - SPACER TUBE
MAF-039506.A3
039506
|
-
|
|
|
|
41 - GUIDE COLUMN, SHORT
MAF-202435.A2
202435
|
-
|
|
|
|
42 - GUIDE COLUMN, LONG
MAF-202434.A10
202434
|
£20.25
|
£24.30
|
|
|
43 - SAW SHAFT
MAF-204001.A2
204001
|
-
|
|
|
|
45 - PRESSURE BOLT
MAF-200034.A1
200034
|
-
|
|
|
|
46 - FLANGE
MAF-203999.A11
203999
|
£15.57
|
£18.68
|
|
|
47 - ECCENTRIC ARBOR
MAF-202433.A1
202433
|
£28.24
|
£33.89
|
|
|
48 - WASHER
MAF-205376.A0
205376
|
-
|
|
|
|
52 - FLANGE
MAF-203998.A6
203998
|
£15.57
|
£18.68
|
|
|
54 - STOP BUFFER
MAF-034209.A18
034209
|
-
|
|
|
|
56 - RETRACTING SPRING
MAF-066090.A6
066090
|
-
|
|
|
|
57 - RETRACTING SPRING
MAF-066091.A7
066091
|
-
|
|
|
|
59 - PRESSURE SPRING
MAF-066043.A71
066043
|
£3.04
|
£3.65
|
|
|
61 - LEG SPRING
MAF-066172.A2
066172
|
-
|
|
|
|
62 - BRUSH HOLDER
MAF-063148.A41
063148
|
£10.30
|
£12.36
|
|
|
63 - CARBON BRUSH
MAF-063173.A1
063173
|
£13.35
|
£16.02
|
|
|
65 - SKALE
MAF-204003.A3
204003
|
-
|
|
|
|
67 - GROOVED BALL BEARING
MAF-006282.A20
006282
|
£14.68
|
£17.62
|
|
|
69 - GROOVED BALL BEARING
MAF-006280.A22
006280
|
£13.65
|
£16.38
|
|
|
71 - WING NUT
MAF-079078.A6
079078
|
-
|
|
|
|
73 - LOCKING WASHER
MAF-061069.A35
061069
|
£1.49
|
£1.79
|
|
|
75 - HANDLE NUT TRIANGULAR
MAF-079079.A1
079079
|
-
|
|
|
|
76 - WING SCREW
MAF-079082.A10
079082
|
-
|
|
|
|
78 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A51
053020
|
-
|
|
|
|
79 - SELF-TAPPING SCREW
MAF-055232.A30
055232
|
£1.68
|
£2.02
|
|
|
81 - SELF-TAPPING SCREW
MAF-055230.A39
055230
|
-
|
|
|
|
83 - CYLINDER-HEAD SCREW
MAF-055096.A29
055096
|
£2.11
|
£2.53
|
|
|
84 - CYLINDER-HEAD SCREW
MAF-055055.A4
055055
|
-
|
|
|
|
85 - CYLINDER-HEAD SCREW
MAF-055234.A13
055234
|
£1.19
|
£1.43
|
|
|
86 - OVAL-HEAD SCREW
MAF-055143.A21
055143
|
-
|
|
|
|
89 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A148
055061
|
£1.71
|
£2.05
|
|
|
90 - THREADED PIN
MAF-005279.A5
005279
|
-
|
|
|
|
91 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A44
055233
|
£1.71
|
£2.05
|
|
|
92 - OVAL-HEAD SCREW
MAF-055264.A0
055264
|
-
|
|
|
|
93 - FLAT-HEAD SCREW
MAF-053029.A22
053029
|
£2.84
|
£3.41
|
|
|
94 - THREADED PIN
MAF-005284.A39
005284
|
-
|
|
|
|
95 - TRUSS-HEAD SCREW
MAF-005718.A6
005718
|
-
|
|
|
|
97 - RETAINING RING
MAF-061138.A3
061138
|
£2.29
|
£2.75
|
|
|
98 - WASHER
MAF-061013.A63
061013
|
-
|
|
|
|
99 - WASHER
MAF-061172.A23
061172
|
-
|
|
|
|
100 - CYLINDRICAL PIN
MAF-058046.A7
058046
|
£2.83
|
£3.40
|
|
|
101 - FLAT-HEAD SCREW
MAF-053031.A28
053031
|
£1.72
|
£2.07
|
|
|
102 - WASHER
MAF-061167.A8
061167
|
£51.32
|
£61.59
|
|
|
103 - SEALING RING
MAF-065042.A5
065042
|
£1.63
|
£1.96
|
|
|
104 - CUP SPRING
MAF-066093.A3
066093
|
-
|
|
|
|
112 - ELECTRONIC MODULE
MAF-205367.A1
205367
|
£105.45
|
£126.54
|
|
|
114 - POLE SHOE
MAF-077093.A2
077093
|
-
|
|
|
|
500 - HOSE CONNECTOR
MAF-200042.A0
200042
|
£14.96
|
£17.95
|
|
|
501 - ALLEN KEY
MAF-093034.A33
093034
|
-
|
|
|
|
502 - PARALLEL GUIDE FENCE
MAF-201436.A4
201436
|
£50.20
|
£60.24
|
|
|
505 - POWER-STATION APS
MAF-094408.A1
094408
|
£137.50
|
£165.00
|
|
|
511 - CARRYING CASE
MAF-095093.A6
095093
|
£140.80
|
£168.96
|
|
|
511.1 - PLASTIC LOCK WITH KEY
MAF-095094.A0
095094
|
£16.62
|
£19.95
|
|
|
512 - PLASTIC TRAY
MAF-205384.A5
205384
|
-
|
|
|
|
530 - ADAPTER FOR PLUG
MAF-078269.A
078269
|
£5.49
|
£6.59
|
|
